Type: LED screens dedicated for indoor and semi-outdoor portable and fixed installation, i.e. information boards, advertising boards, video walls
Application: Conference, congress and symposium events, exhibitions fairs, concert scenes, store windows
Distinguishing feature: Fast in assembling and dismantling, easy in transportation
| Pixel pitch: | 4 mm(0.16in) | 5 mm(0.20in) | 6 mm(0.24in) | 7.62 mm(0.3in) |
| Pixel Density (pixels/m2) | 62,500 | 40,000 | 27,777 | 17,222 |
| Pixel Configuration | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 |
| Module Dimension | 128*128mm(5.04*5.04in) | 160*160mm(6.30*6.30in) | 192*96mm(7.56*3.78in) | 244*122mm(9.61*4.80in) |
| Module Resolution (pixels) | 32*32 | 32*32 | 32*16 | 32*16 |
| Cabinet Dimensions | 512*512mm(20.16*20.16in) | 640*640mm(25.20*25.20in) | 768*768mm(30.24*30.24in) | 488*488mm(19.21*19.21in) |
| Cabinet Resolution (pixels) | 128*128 | 128*128 | 128*128 | 64*64 |
| Brightness (nits) | 1,200 | 1,800 | 2,000 | 2,200 |
| Max Power consumption (W/m2) | 600 | 650 | 750 | 800 |
| Best viewing distance (m) | 5~13 | 6~17 | 8~20 | 9~23 |
| Viewing angle | Horizontal: 140o, Vertical: 140o | |||
| Gray Scale levels (bits) | 16 | 16 | 16 | 16 |
| Refresh rate (Hz) | >1000 | >1000 | >1000 | >1000 |
| Protection rating | IP40 | IP40 | IP40 | IP40 |
| LED lifetime (hours) | 100,000 | 100,000 | 100,000 | 100,000 |
| Input voltage | 90~ 260VAC, 50/60Hz | |||
| Humidity range | 10%~99% | 10%~99% | 10%~99% | 10%~99% |
| Temperature Range | -20 ~60 | -20 ~60 | -20 ~60 | -20 ~60 |
Parameters can be modified according to the individual order.
